Presentation

Find all the service models dedicated to the supervision of your Storage - Storage P 4500.

Service Models

BOX mode

HP-P4000-Disk-Temperature

Collects the temperature of the disks of a P4000 node. Switches to ALERT / CRITICAL state if the temperature of at least one disk of the node exceeds the value of the indicated thresholds. Configuration: SNMP community, SNMP version, SNMP port, node IP address, alert threshold, critical threshold. This model is intended for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Fan-Status

Collects the status of the fans on a P4000 node. Switches to CRITICAL status if the status of at least one fan is not normal. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Inventory

Collects essential information about an HP P4000 node: model, name, serial number, software version, BIOS version. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-network-Status

Collects the status of network devices on a P4000 node. Switches to CRITICAL status if the status of at least one network device is not active. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This model is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-PS-Status

Collects the status of the power supplies of a P4000 node. Switches to CRITICAL status if the status of at least one power supply is not normal. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Raid-Status

Collects the status of the RAID devices on a P4000 node. Switches to ALERT state if at least one of them is rebuilding, to CRITICAL state if at least one of them is degraded. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This model is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Temperature

Collects the temperature of a P4000 node at multiple sensors. Switches to ALERT / CRITICAL state if the state of at least one temperature sensor exceeds the value of the indicated thresholds. Configuration: SNMP community, SNMP version, SNMP port, node IP address, alert threshold, critical threshold. This model is intended for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Cache-BPS-Status

Collects the standby cache status of the controllers on a P4000 node. Switches to CRITICAL state if the standby cache status of at least one controller is not normal. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Cache-Status

Collects the cache status of the controllers in a P4000 node. Switches to CRITICAL state if the cache status of at least one controller is not normal. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Cluster-Quorum

Collects the quorum status of a P4000 cluster. Switches to ALERT status if the number of active managers on the cluster is greater than or equal to the required quorum, but some managers are inactive; displays the inactive managers. Switches to the CRITICAL state if the number of active managers on the cluster is less than the required quorum, and displays the non-active managers. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-cluster-volume

Checks the free space on the volumes of a P4000 cluster. Switches to CRITICAL state if at least one of the volumes is full, and displays the volumes in this case. Configuration: SNMP community, SNMP version, SNMP port, cluster IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Cluster-VolumeFull

Checks the disk space used on a volume of a StoreVirtual / Lefthand SAN. Alerts if it exceeds a certain threshold. Thresholds are expressed as a percentage of the volume size. Configuration : SNMP monitoring account, volume name, thresholds.

Available from version 3.13

HP-P4000-Cluster-Volume-IOPS

Collects the number of pending read and write operations on the volume of an HP P4000 cluster specified as an argument. Switches to ALERT/CRITICAL state when thresholds are crossed. If no volume is specified, the check is performed on all volumes. Configuration: SNMP community, SNMP version, SNMP port, node IP address, volume name, alert threshold for read operations, critical threshold for read operations, alert threshold for write operations, critical threshold for write operations. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Cluster-Volume-iSCSIsessions

Collects the number of iSCSI sessions on the volume of a P4000 cluster specified as an argument. Switches to ALERT/CRITICAL state when thresholds are crossed. If no volume is specified, the check is performed on all volumes. Configuration: SNMP community, SNMP version, SNMP port, cluster IP address, volume name, alert threshold, critical threshold. This model is intended for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Cluster-VolumeStatus

Collects the status of the volumes in a P4000 cluster. Switches to CRITICAL status if at least one of the volumes is unavailable due to a replication problem, and displays the volumes in this case. Configuration: SNMP community, SNMP version, SNMP port, cluster IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Disk-Connected

Collects the presence of disks on a P4000 node. Switches to CRITICAL state if at least one of the disks is not physically connected to the node. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13

HP-P4000-Disk-SmartStatus

Collects the SMART status of the disks in a P4000 node. Switches to CRITICAL status if the SMART status of at least one disk is not normal. Configuration: SNMP community, SNMP version, SNMP port, node IP address. This template is for HP P4x00 devices with SAN/iQ version 8.5 and higher.

Available from version 3.13
