ServiceNav 4.16

Huawei Dorado service models, MariaDB, Riverbed, various patches

17/05/2021

New

Service Models: Riverbed, MariaDB, Dorado

This minor version brings new service modelsas well as various patches.

Evolution

User Services - Removing action templates

The action templates have been removed from the User Services.
The use of this historical feature had become very rare, and we want to offer you high value features, in a clear interface. This means identifying and removing the least used/relevant elements, or where other more recent features duplicate them.

Evolution

Complete list of developments

VSWA-29367 Delete action templates for user services
VSWA-22837 [Box] Riverbed-bwoptimization - check_snmp_riverbed_bwoptimization
VSWA-19378 [Box] Template MS-Exchange-DAG-Replication-Status: collect using protocol WinRM

Correction

Complete list of patches

VSWA-29889 [Box] MS-Exchange-DAG-Replication-Status - check_ps_ms_exch_DAG_replication - the example connection method argument is not translated
VSWA-29837 The start and end dates of maintenance on the popup on the bigdata technical operation are erroneous
VSWA-29752 Performance Analysis Report: Missing Data
VSWA-29652 check_snmpv3_auth_priv_lin_load command - Wrong argument type
VSWA-29526 [Box] IBM-V7000-Disk-Status - check_ibm_v7000_svc.pl - Return error
VSWA-29496 Performance report - Missing CPU data
VSWA-29111 [Box] IBM-AS400-Cpu-Usage - check_snmp_as400_load - nagios thresholds should not appear in perfdata
VSWA-24978 SUT - HS Notification on Change of Status

Service Models

New
  • Applicatif

Riverbed-Bandwidth-Optimization

Collects optimized traffic volume across all ports of a Riverbed device. Configuration: community, SNMP version and port, warning and critical thresholds.


  • Applicatif

MariaDB-BufferPool-HitRate

Controls the Buffer Pool usage of InnoDB tables. Measures the success rate and alerts if it is below a threshold. Configuration: MariaDB monitoring account (use MySQL account), TCP port to connect to the server, percentage thresholds.


  • Applicatif

MariaDB-BufferPool-WaitFree

Number of occurrences / second where we wait for the Buffer Pool to be available. Alert if it reaches an alert threshold Configuration: MariaDB supervision account (use MySQL account), TCP connection port, thresholds.


  • Applicatif

MariaDB-ConnectionTime

Controls the establishment of the connection to the MySQL server. Measures the time to establish the connection. Alerts if this delay is higher than a threshold. Configuration: MariaDB monitoring account (use MySQL account), MySQL server connection port.


  • Applicatif

MariaDB-Databases

Get the size of the databases and notify if the server is not accessible. Configuration : account on MariaDB server (use MySQL account), databases


  • Applicatif

MariaDB-Index-Usage

Collects the rate of index usage by queries on the MariaDB database. This control notifies when a threshold is exceeded. Configuration: account and password of a user with USAGE access to the MariaDB database (use the MySQL account), alert threshold, critical threshold. The alert threshold is higher than the critical threshold.


  • Applicatif

MariaDB-KeyCache-HitRate

Controls the key cache usage of MyISAM tables. Measures the hit rate and alerts if it is below a certain threshold. Configuration: MariaDB supervision account (use MySQL account), TCP port of connection to the server, thresholds in percentage.


  • Applicatif

MariaDB-LogWaits

Controls the number of times per second that the database waits for the InnoDB log to be written to disk. A value too high indicates that this log is too small. Alert when this value exceeds a threshold. Configuration : MariaDB supervision account (use MySQL account), TCP connection port, alert thresholds.


  • Applicatif

MariaDB-Long-Running-Procs

Collects the number of MariaDB processes whose execution time exceeds one minute. This control notifies when the threshold is exceeded. Configuration: account and password of a user with USAGE access to the MariaDB database (use MySQL account), alert threshold, critical threshold.


  • Applicatif

MariaDB-Modified-Configuration

Verifies that the MariaDB server configuration has not been changed. Alerts if any changes have been made and specifies which directives have been changed. Configuration: MariaDB supervision account (use MySQL account), MariaDB server connection port, configuration checksum.
The configuration is done in two steps.
We set the checksum parameter to 0 to initialize the check. This one returns the initial checksum corresponding to the current MariaDB configuration.
The checksum parameter is then defined with the one returned previously.


  • Applicatif

MariaDB-Open-Connections

Collects the number of current connections to the MariaDB database. This control notifies when a threshold is exceeded. Configuration: account and password of a user with USAGE access to the MariaDB database (use MySQL account), alert threshold, critical threshold.


  • Applicatif

MariaDB-OpenFiles

Checks the number of open files against the maximum limit for the MySQL server. Alerts if this rate exceeds a threshold. Configuration: MariaDB monitoring account (use MySQL account), connection port, thresholds as a percentage of the maximum limit.


  • Applicatif

MariaDB-QueryCache-HitRate

Controls the cache usage of SQL queries. Measures the success rate and alerts if it is below a threshold. Configuration: MariaDB monitoring account (use MySQL account), TCP port to connect to the server, percentage thresholds.


  • Applicatif

MariaDB-QueryCache-LowMemoryPrunes

Measures the number of queries/sec out of the query cache that occur due to a memory shortage. Alerts if this number exceeds a threshold. A high value may indicate a too small query cache size. Configuration: MariaDB monitoring account (use MySQL account), TCP connection port, alert thresholds.


  • Applicatif

MariaDB-Replication-Delay

Collects the replication delay, in seconds, from the master MariaDB server to the slave MariaDB server. This control notifies when the threshold is exceeded. Configuration: account and password of a user with CLIENT REPLICATION access to the MariaDB database (use MySQL account), alert threshold, critical threshold.


  • Applicatif

MariaDB-Request

Executes a SQL query returning a number. Configuration : MariaDB monitoring account (use MySQL account), TCP connection port, thresholds, SQL query.


  • Applicatif

MariaDB-Request-String

Executes a SQL query on a database and returns a String value. Changes state if the first column of the query matches or doesn't match the searched string. If a second column is part of the result of the query then its content is displayed in the plugin output. Configuration: an account and a password of a MariaDB user (use the MySQL account) having the rights of execution of the request, name of the base, SQL request, sought string (possible regex), status of presence, status of absence. Prerequisite: The query must return only one row. The first column is compared with the string. The second column is used to display an additional text in the plugin output.


  • Applicatif

MariaDB-SlaveIO

Checks if the IO replication process is running. Alerts if it is not. Configuration: MariaDB monitoring account (use MySQL account), TCP connection port.


  • Applicatif

MariaDB-SlaveSQL

Checks if the SQL replication process is running. Alerts if it is not. Configuration: MariaDB monitoring account (use MySQL account), TCP connection port.


  • Applicatif

MariaDB-Slow-Queries

Collects the rate of requests classified as slow on the MariaDB server. This control notifies when the threshold is exceeded. Configuration: account and password of a user with USAGE access to the MariaDB database (use MySQL account), alert threshold, critical threshold.


  • Applicatif

MariaDB-Table-Lock-Contention

Collects the rate of failed table locks on the MariaDB database. This control notifies when a threshold is exceeded. Configuration: account and password of a user with USAGE access to the MariaDB database (use MySQL account), alert threshold, critical threshold.


  • Applicatif

MariaDB-TableCacheHitRate

Controls table cache usage. Measures the table cache hit rate. Alerts if it is below a certain threshold. This control is done only when the fill rate of this cache is higher than 95%. Configuration: MariaDB supervision account (use MySQL account), TCP port of connection to the server, thresholds in percentage.


  • Applicatif

MariaDB-ThreadCacheHitRate

Controls the use of the thread cache. Measures the rate of use of this cache and alerts when this rate goes below a threshold. Configuration: MariaDB monitoring account (use MySQL account), MariaDB server connection port, thresholds expressed in percentage.


  • Applicatif

MariaDB-Tmp-Disk-Tables

Collects the rate of temporary tables created on disk rather than in memory, on the MariaDB database. This control notifies when a threshold is exceeded. Configuration: account and password of a user with USAGE access to the MariaDB database (use a MySQL account), alert threshold, critical threshold.


  • Applicatif

MariaDB-Uptime

Duration since the last restart of the server (takes into account the restarts and the crashes). Configuration : MariaDB supervision account (use the MySQL account), TCP port of connection to the MariaDB server, thresholds expressed in seconds and respecting the nagios format:
XX: alert if above XX
XX: : alert if below XX
XX:YY : alert if not between XX and YY


  • Storage - Storage

Huawei-Dorado-Disk-PhysicalStatus

Monitors the health of the disks in a Dorado storage array and alerts if at least one disk is in error. Configuration SNMP community, SNMP version, SNMP port, white list, black list


  • Storage - Storage

Huawei-Dorado-Disk-RunningStatus

Checks the operating status of the disks in a Dorado array and alerts if at least one disk is in error. Configuration SNMP community, SNMP version, SNMP port, white list, black list


  • Storage - Storage

Huawei-Dorado-Disk-Temperature

Monitors the temperature of the disks in a Dorado storage array and alerts if the temperature of at least one disk exceeds the thresholds. Configuration SNMP community, SNMP version, SNMP port, white list, black list


  • Storage - Storage

Huawei-Dorado-Disk-Usage

Collects the percentage of disk space used by a Dorado storage array. Configuration SNMP community, SNMP version, SNMP port, alert threshold, critical threshold


  • Storage - Storage

Huawei-Dorado-Fan-HealthStatus

Monitors the health of the fans in a Dorado storage array and alerts if at least one fan is in error. Configuration SNMP community, SNMP version, SNMP port, white list, black list


  • Storage - Storage

Huawei-Dorado-LUN-Status

Monitors the status of LUNs in a Dorado storage array and alerts if at least one LUN is in error. Configuration SNMP community, SNMP version, SNMP port, white list, black list


  • Storage - Storage

Huawei-Dorado-Nodes-CPU-Usage

Collects the CPU usage of Dorado nodes. Configuration SNMP community, SNMP version, SNMP port, white list, black list, alert threshold, critical threshold


  • Storage - Storage

Huawei-Dorado-Nodes-Memory-Usage

Collects the memory usage of Dorado nodes. Configuration SNMP community, SNMP version, SNMP port, white list, black list, alert threshold, critical threshold


  • Storage - Storage

Huawei-Dorado-Nodes-Total-IOPS

Collects the total amount of IOPS processed by nodes in a Dorado storage array, and alerts if at least one node is in error. Configuration SNMP community, SNMP version, SNMP port, white list, black list, alert threshold, critical threshold


  • Storage - Storage

Huawei-Dorado-PowerSupply-HealthStatus

Monitors the health of the power supplies in a Dorado storage array and alerts if at least one power supply is in error. Configuration SNMP community, SNMP version, SNMP port, white list, black list

Evolution
0
Florian Mattes
Product Manager ServiceNav
